VF380 is a new generation facial identification terminal with Face, RFID and PIN Recognition mode and Access Conntrol
With latest facial algorithm ZK Face 7.0 and large capacity ZEM810 platform, it holds 200 face templates without dividing groups, and its verification time is less than 1 Second. All setting operations are easily done on 3.0 inches TFT touch screen. The elegant and small size design can fit with your slap-up office. Have ZK Face identification system, your life will become more secure and convenient.
Download PDF : zkt-VF380_brochure
Features
Optional
Features
- Elegant ergonomic design
- Relay for Access Control
- TCP/IP communication and USB Host.
- 3.0 inch TFT touch screen, T9 Input, 9 Digit User ID.
- Infra-red optical system enables user-identification in poorly lit environments.
- Optional Mifare card module
- Professional facial identification algorithm
Capacity
| Face Capacity | 400 (1:N); optional up to 800 |
| ID Card Capacity | 10.000 |
| Logs Capacity | 100.000 |
Hardware
| Platform | ZEM810 |
| Sensor | Special Image Stereo Dual Sensor |
Display
| LCD | 3’’ TFT Touch Screen |
| LED Indicator | Green / Red |
Environment
| Oper. Temp | 0°-45°C |
| Oper. Humidity | 20%-80% |
Power
| Power | 12V, DC 3A |
Communication
| Comm. Port | Ethernet |
| Pen drive | USB Host |
Face Algorithm
| Type | ZKFace7.0 |
| Verification | <=1 sec |
Proximity Module
| Type | EM card |
| Identification | <=1 sec |
Languages
| Available | All European languages |
| Maximum | 7 |
| Voices | Allowed |
Keypad
| Type | Touch-sensitive keypad |
| Function Keys | 6 (Defined by user) |
Dimensions
| Dimensions | 193.6×146.8x111mm (L x W x D) |
| Weight | 1.65kg |
Firmware
| O.S | Linux |
| Applications | T&A, AC (groups and TZ) |
| SDK | Standard SDK |
